- Visual Studio Code
// Ray Marching
float4 res = float4(.0, .0, .0, .0);
float t = .0;
for (int step_march = 0; step_march < 100; ++step_march)
{
float3 p = ro + t * rd;
float h = CustomExpression0(Parameters,p);
if(h < .001)
{
float2 eps = float2(.0001, .0);
float3 N = normalize(float3(
CustomExpression0(Parameters, p + eps.xyy) - CustomExpression0(Parameters, p - eps.xyy),
CustomExpression0(Parameters, p + eps.yxy) - CustomExpression0(Parameters, p - eps.yxy),
CustomExpression0(Parameters, p + eps.yyx) - CustomExpression0(Parameters, p - eps.yyx)
));
res = float4(N, 1.f);
break;
}
t += h;
}
return res;
// Map
struct Funcs
{
float smin(float a, float b, float k)
{
float h = max(k - abs(a-b), .0) / k;
return min(a, b) - h * h * k * (1./4.);
}
};
Funcs f;
float iTime = View.GameTime;
float d1 = length(p - float3(30. * cos(iTime), .0, .0)) - 40.;
float an = 2. * sin(iTime);
float2x2 rot = float2x2(
cos(an), -sin(an),
sin(an), cos(an)
);
float3 q = p;
q.yz = mul(rot, q.yz);
float d2 = length(float2(q.y, length(q.xz) - 80.)) - 20.;
float d = f.smin(d1, d2, .5);
return d;
